As a premier manufacturer and global supplier of fluid transfer equipment, we engineer manual dispensing solutions that optimize operational efficiency. This manual nozzle is meticulously crafted for heavy-duty fuel management, delivering precise control and unwavering reliability in demanding industrial and agricultural environments.
Engineered from lightweight, high-strength aluminum for maximum longevity.
Specifically designed for gravity-fed and low-pressure fluid systems.
Highly compatible with diverse liquid fuels including diesel, gasoline, and kerosene.
Manufactured in strict accordance with international safety and quality protocols.
When managing high-volume fluid transfer operations, equipment failure is simply not an option. This manual dispensing nozzle is meticulously engineered to provide an unparalleled tactile experience alongside seamless operational fluidity. Grasping the cool, powder-coated aluminum chassis instantly conveys a sense of rugged durability, while the meticulously balanced weight distribution eliminates wrist strain during prolonged, high-capacity fueling sessions. The distinct, satisfying mechanical click of the trigger mechanism offers immediate physical feedback, ensuring operators maintain absolute, nuanced control over the liquid flow rate. Designed intentionally without complex, failure-prone automatic shut-off mechanisms, this tool thrives in harsh environments where simplicity and raw reliability are paramount. Whether dispensing diesel into heavy agricultural machinery under a scorching sun or transferring kerosene in a dusty, high-traffic industrial depot, the smooth internal fluid path minimizes turbulence, delivering a quiet, remarkably steady stream of fuel. By eliminating unnecessary internal flow restrictions, this equipment maximizes throughput, allowing your operational teams to complete their fueling tasks swiftly and move on to the next objective, thereby significantly reducing vehicle downtime and enhancing overall site productivity.
The following technical data outlines the precise engineering parameters and material specifications of the unit, ensuring it meets the rigorous demands of your fluid management infrastructure.
| Specification Criteria | Technical Parameters |
|---|---|
| Product Series | TDW-A Series Manual Nozzle |
| Main Body Material | High-Strength Aluminum |
| Spout Material | Aluminum |
| Seals Material | Buna-N (Nitrile Rubber) / Viton |
| Swivel Joint Material | Stainless Steel |
| Inlet Size Options | 3/4" or 1" |
| Spout Outer Diameter | 16mm (13/16") or 19mm (15/16") |
| Thread Standards | NPT / BSP / BSPT |
| Maximum Flow Rate | 40 L/min (16mm spout) or 60 L/min (19mm spout) |
| Standard Working Pressure | 0.2 MPa |
| Net Weight | Approximately 0.8 KG |
| Applicable Media | Diesel, Gasoline, Kerosene, General Liquid Fuels |
| Certifications | ISO9001, ATEX, UL (supported on select models) |
Equipping your facility with the right fluid transfer tools directly impacts your operational bottom line by reducing accidental spillage, lowering long-term maintenance costs, and accelerating daily workflows. This manual nozzle is built around the core philosophy of relentless performance, ensuring that every drop of liquid is transferred exactly where it needs to go without hesitation or leakage. The design prioritizes the user's physical comfort and the organization's need for uninterrupted, high-speed fluid delivery.
Tactile Precision Trigger: The ergonomically contoured lever provides progressive mechanical resistance, allowing the operator to feather the flow from a mere trickle to a full-bore surge with pinpoint accuracy.
Integrated Storage Hook: A heavy-duty cast hook positioned on the top shield allows for secure, immediate hanging on storage tanks or dispensers, keeping the spout off the ground and free from abrasive dirt.
Streamlined Fluid Dynamics: The internal chamber is machined to exacting tolerances, significantly reducing fluid cavitation and ensuring a laminar flow that prevents hazardous splashing and vapor release.
Weather-Resilient Exterior: The robust aluminum housing naturally resists oxidation and environmental degradation, maintaining its structural integrity even when exposed to harsh ultraviolet light or freezing ambient temperatures.
To truly understand the value this equipment brings to your operational infrastructure, it is essential to examine its core engineering dimensions. Every aspect of its construction has been optimized to solve real-world fluid management challenges.
The main body and spout are forged from a proprietary lightweight aluminum alloy, perfectly paired with a rugged stainless steel swivel and chemical-resistant Buna-N or Viton seals. This formidable construction creates an impenetrable barrier against rust and corrosion, easily enduring the brutal, high-impact realities of agricultural and industrial environments without succumbing to structural fatigue or hazardous leaks.
Engineered for universal integration, the unit offers inlet sizes of 3/4" and 1", alongside spout diameters of 16mm and 19mm. By fully supporting NPT, BSP, and BSPT international thread standards, it seamlessly connects to global fuel dispensers, mobile tanks, and hose setups. Procurement teams can specify this hardware with absolute confidence, eliminating the costly downtime associated with mismatched fittings.
Optimized specifically for gravity-fed and low-pressure applications, the system maintains a stable working pressure of 0.2 MPa while unleashing a maximum flow rate of 60 L/min. This rapid transfer capability drastically reduces the time required to refuel agricultural tractors, heavy commercial fleets, and above-ground storage tanks, transforming a time-consuming chore into a swift, highly efficient process.
Weighing in at a mere 0.8 KG, the perfectly balanced chassis virtually eliminates operator arm fatigue during repetitive use. The inclusion of a 360-degree stainless steel swivel at the base eradicates frustrating hose kinks and twists, while the integrated hanging hook ensures immediate, safe storage, dramatically improving site organization and prolonging equipment lifespan.
Boasting exceptional chemical compatibility, the internal seals and metallic pathways confidently handle diesel, gasoline, kerosene, and a wide spectrum of standard liquid fuels. It stands as the definitive fluid transfer solution for remote farms, busy construction sites, mining operations, and non-commercial gravity-fed fueling stations.
Safety is never left to chance. Every single unit undergoes a rigorous 100% factory testing protocol for absolute seal integrity and mechanical performance. Manufactured under strict ISO9001 quality management systems and compliant with ATEX and UL safety standards (on select models), it guarantees uncompromising security during high-frequency, daily utilization.
Backed by nearly three decades of direct manufacturing expertise, we provide unparalleled customization options including distinct colorways, bespoke branding, and tailored packaging. We empower volume purchasers with comprehensive sample testing, a full one-year warranty, and highly competitive pricing structures, ensuring a frictionless procurement journey and steadfast post-purchase support.
Selecting a manufacturing partner for your industrial equipment needs requires absolute trust in their production capabilities and dedication to your long-term success. We do not merely assemble components; we engineer comprehensive solutions designed to elevate your operational capabilities and protect your capital investments. Partnering with us means securing a direct pipeline to premium manufacturing excellence.
Direct-from-Source Economics: By controlling the entire production lifecycle, we eliminate intermediary markups, delivering premium-grade hardware at highly aggressive pricing structures that protect your operational margins.
Uncompromising Quality Assurance: Our testing facilities simulate the harshest real-world conditions. If a unit does not pass our meticulous pressure and flow consistency checks, it never leaves our facility.
Agile Customization: We understand that equipment often needs to align with specific corporate identities or regional regulations. Our rapid-response engineering team seamlessly integrates your specific design and branding requirements.
Dedicated Global Support: From initial technical consultations to post-deployment troubleshooting, our seasoned fluid dynamics experts are always on standby to ensure your operations run without interruption.
Reliable Production Capacity: Leveraging advanced manufacturing lines, we guarantee stable, predictable lead times even for the most substantial volume orders, keeping your supply chain resilient and predictable.
Navigating the technical nuances of industrial fluid transfer can be complex. Below, we address the most critical inquiries from procurement professionals and site engineers to assist in your strategic decision-making process.
Manual designs strip away complex internal valving, resulting in a significantly lower pressure drop and a much higher flow rate in gravity-fed or low-pressure systems. They are inherently more robust, easier to maintain in the field, and completely immune to the false-shutoff issues that constantly plague automatic models in turbulent flow conditions.
The integrated swivel drastically reduces the physical strain placed on the heavy rubber dispensing hose. By allowing the hose to rotate freely along its axis, it prevents torsion damage, eliminates frustrating kinking, and makes maneuvering the heavy-duty nozzle into awkward vehicle receptacles virtually effortless.
While both offer excellent structural resistance, they cater to different chemical profiles. Buna-N is exceptional for standard diesel and gasoline applications, offering tremendous tear resistance. Viton provides superior performance for harsher chemicals, synthetic fuels, or environments experiencing extreme temperature fluctuations. We configure the seals precisely based on your specific media requirements.
Absolutely. It is specifically engineered to excel in low-pressure environments. With a minimal working pressure requirement of just 0.2 MPa, the optimized internal fluid path ensures you still achieve excellent flow rates (up to 60 L/min) relying solely on the gravitational head pressure of your storage tank.
We offer extensive tailoring for volume orders. This includes custom powder-coating colors to match your corporate branding, laser-etched logos directly on the chassis, specific thread standard selections (NPT/BSP/BSPT) to match regional infrastructure, and custom retail or industrial packaging formats designed to streamline your distribution.
